GAS TURBINE EXHAUST SILENCERS

Gas Turbine Exhaust Silencer

Schock Manufacturing personnel have extensive experience with both design and fabrication of Gas Turbine exhaust silencers for large frame turbines. The firing temperatures and run conditions have increased the challenge.

Material selections, Exhaust Silencer thermal design, fabrication methods, and internal fill materials are all critical items that must be considered. This makes selecting your partner a key decision for your plant.

At Schock, we start with a free thorough inspection, and offer a comprehensive report. We will work with your plant personnel and engineering groups for a interactive discussion to find the best solution. Should a complete replacement be necessary, we will evaluate carefully to offer the most economical turnkey solution.

Please call us today to discuss your maintenance needs.

Contact Shock

Exhaust Silencers

Gas Turbine Exhaust Silencer Step 1

Step 1

Schedule a free inspection

Gas Turbine Exhaust Silencer Step 2

Step 2

Schock will submit a free equipment condition report, along with suggested upgrades or repairs

Gas Turbine Exhaust Silencer Step 3

Step 3

Schock will deliver your gas turbine exhaust silencer package designed and fabricated in the central United States

Gas Turbine Exhaust Silencer Step 4

Step 4

We can offer turnkey installation or TFA assistance for your gas turbine exhaust silencers

Gas Turbine Exhaust Silencer Step 5

Step 5

Schock will issue a final field report

Gas Turbine Exhaust Silencer Step 6

Step 6

Run your GT

Upgrade (Vertical)

Vertical Gas Turbine Exhaust Silencer Step 1

Step 1

Prepare the lifting device

Vertical Gas Turbine Exhaust Silencer Step 2

Step 2

Prepare for stack removal

Vertical Gas Turbine Exhaust Silencer Step 3

Step 3

Remove stack

Vertical Gas Turbine Exhaust Silencer Step 4

Step 4

Remove baffles

Vertical Gas Turbine Exhaust Silencer Step 5

Step 5

Support adjustment

Vertical Gas Turbine Exhaust Silencer Step 6

Step 6

Re-install baffles

Vertical Gas Turbine Exhaust Silencer Step 7

Step 7

Install baffles ties

Vertical Gas Turbine Exhaust Silencer Step 8

Step 8

Lift stack into place

Vertical Gas Turbine Exhaust Silencer Step 9

Step 9

Re-install internal liner

Vertical Gas Turbine Exhaust Silencer Step 10

Step 10

Weld out stack

Upgrade (Horizontal)

Horizontal Gas Turbine Exhaust Silencer Step 1

Step 1

Prepare for roof removal

Horizontal Gas Turbine Exhaust Silencer Step 2

Step 2

Remove roof

Horizontal Gas Turbine Exhaust Silencer Step 3

Step 3

Prepare for panel removal

Horizontal Gas Turbine Exhaust Silencer Step 4

Step 4

Panel Removal

Horizontal Gas Turbine Exhaust Silencer Step 5

Step 5

Floor support evaluation

Horizontal Gas Turbine Exhaust Silencer Step 6

Step 6

Floor & insulation removal

Horizontal Gas Turbine Exhaust Silencer Step 7

Step 7

Add supports, insulation & liner

Horizontal Gas Turbine Exhaust Silencer Step 8

Step 8

Re-install panels

Horizontal Gas Turbine Exhaust Silencer Step 9

Step 9

Add panel ties

Horizontal Gas Turbine Exhaust Silencer Step 10

Step 10

Re-install roof

The Difference is Obvious

Gas Turbine Exhaust Silencer Full Weld Joints

Schock Manufacturing

Full welds across the joint

Gas Turbine Exhaust Silencer Partial Welds

The "other" Supplier

Partial welds across the joint

Turbine Exhaust Systems

Gas Turbine Exhaust Silencer Upgrade

501FD Exhaust Silencer Upgrade

These panels were designed to fit on existing support brackets

Gas Turbine Exhaust Stack Removal

Gas Turbine Exhaust Stack Removal

Removal of stack to access vertical silencer area
